RUD sling and lashing systems

PP-B PowerPoint® ring connection, UNC thread

Easy to rotate and always the right connection

Rotating 360°, pivoting 230°
Universal, unmistakable VIP connection for chain, hook and eye
Double ball bearing for turning/rotating operations

PowerPoint PP-B-0,63t-1/2"-13UNC (7989901)

Article number: 7989901

PowerPoint PP-B-0,63t-1/2-13UNC

Attribute	Value	Value
Attributeweight	Value0.35 kg	Value0.77 lbs
AttributeNominal WLL	Value630 kg	Value1385 lbs
AttributeT	Value106 mm	Value4-3/16"
AttributeA	Value9 mm	Value11/32"
AttributeB	Value65 mm	Value2-9/16"
AttributeC	Value35 mm	Value1-3/8"
AttributeD	Value40 mm	Value1-9/16"
AttributeE	Value36 mm	Value1-27/64"
AttributeF	Value18 mm	Value23/32"
AttributeG	Value41 mm	Value1-5/8"
AttributeM	Value1/2"-13UNC mm	Value1/2"-13UNC
AttributeN	Value15 mm	Value19/32"

PowerPoint PP-B-1,5t-5/8"-11UNC (7989902)

Article number: 7989902

PowerPoint PP-B-1,5t-5/8-11UNC

Attribute	Value	Value
Attributeweight	Value0.50 kg	Value1.10 lbs
AttributeNominal WLL	Value1500 kg	Value3300 lbs
AttributeT	Value115 mm	Value4-1/2"
AttributeA	Value11 mm	Value7/16"
AttributeB	Value65 mm	Value2-9/16"
AttributeC	Value35 mm	Value1-3/8"
AttributeD	Value46 mm	Value1-13/16"
AttributeE	Value41 mm	Value1-5/8"
AttributeF	Value24 mm	Value15/16"
AttributeG	Value50 mm	Value1-31/32"
AttributeM	Value5/8"-11UNC mm	Value5/8"-11UNC
AttributeN	Value15 mm	Value19/32"

PowerPoint PP-B-2,5t-3/4"-10UNC (7989903)

Article number: 7989903

PowerPoint PP-B-2,5t-3/4-10UNC

Attribute	Value	Value
Attributeweight	Value1.10 kg	Value2.43 lbs
AttributeNominal WLL	Value2500 kg	Value5500 lbs
AttributeT	Value135 mm	Value5-5/16"
AttributeA	Value13 mm	Value1/2"
AttributeB	Value75 mm	Value2-15/16"
AttributeC	Value40 mm	Value1-9/16"
AttributeD	Value61 mm	Value2-13/32"
AttributeE	Value55 mm	Value2-5/32"
AttributeF	Value30 mm	Value1-3/16"
AttributeG	Value61 mm	Value2-13/32"
AttributeM	Value3/4"-10UNC mm	Value3/4"-10UNC
AttributeN	Value18 mm	Value23/32"

PowerPoint PP-B-2,5t-7/8"-9UNC (7989904)

Article number: 7989904

PowerPoint PP-B-2,5t-7/8-9UNC

Attribute	Value	Value
Attributeweight	Value1.10 kg	Value2.43 lbs
AttributeNominal WLL	Value2500 kg	Value5500 lbs
AttributeT	Value135 mm	Value5-5/16"
AttributeA	Value13 mm	Value1/2"
AttributeB	Value75 mm	Value2-15/16"
AttributeC	Value40 mm	Value1-9/16"
AttributeD	Value61 mm	Value2-13/32"
AttributeE	Value55 mm	Value2-5/32"
AttributeF	Value30 mm	Value1-3/16"
AttributeG	Value61 mm	Value2-13/32"
AttributeM	Value7/8"-9UNC mm	Value7/8"-9UNC
AttributeN	Value18 mm	Value23/32"

PowerPoint PP-B-4t-1"-8UNC (7989905)

Article number: 7989905

PowerPoint PP-B-4t-1-8UNC

Attribute	Value	Value
Attributeweight	Value2.40 kg	Value5.29 lbs
AttributeNominal WLL	Value4000 kg	Value8800 lbs
AttributeT	Value172 mm	Value6-25/32"
AttributeA	Value16 mm	Value5/8"
AttributeB	Value95 mm	Value3-3/4"
AttributeC	Value45 mm	Value1-25/32"
AttributeD	Value78 mm	Value3-1/16"
AttributeE	Value70 mm	Value2-3/4"
AttributeF	Value36 mm	Value1-27/64"
AttributeG	Value77 mm	Value3"-1/32"
AttributeM	Value1"-8UNC mm	Value1"-8UNC
AttributeN	Value20 mm	Value3/4"

PowerPoint PP-B-5t-1 1/4"-7UNC (7989906)

Article number: 7989906

PowerPoint PP-B-5t-1 1/4-7UNC

Attribute	Value	Value
Attributeweight	Value5.20 kg	Value11.46 lbs
AttributeNominal WLL	Value5000 kg	Value11000 lbs
AttributeT	Value223 mm	Value8-25/32"
AttributeA	Value21 mm	Value13/16"
AttributeB	Value130 mm	Value5-1/8"
AttributeC	Value60 mm	Value2-3/8"
AttributeD	Value95 mm	Value3-3/4"
AttributeE	Value85 mm	Value3-11/32"
AttributeF	Value45 mm	Value1-25/32"
AttributeG	Value93 mm	Value3-21/32"
AttributeM	Value1 1/4"-7UNC mm	Value1 1/4"-7UNC
AttributeN	Value25 mm	Value63/64"

PowerPoint PP-B-8t-1 1/2"-6UNC (7989907)

Article number: 7989907

PowerPoint PP-B-8t-1 1/2-6UNC

Attribute	Value	Value
Attributeweight	Value6.30 kg	Value13.89 lbs
AttributeNominal WLL	Value8000 kg	Value17600 lbs
AttributeT	Value242 mm	Value9-7/32"
AttributeA	Value24 mm	Value15/16"
AttributeB	Value140 mm	Value5-1/2"
AttributeC	Value65 mm	Value2-9/16"
AttributeD	Value100 mm	Value3-15/16"
AttributeE	Value90 mm	Value3-17/32"
AttributeF	Value54 mm	Value2-1/8"
AttributeG	Value102 mm	Value4"
AttributeM	Value1 1/2"-6UNC mm	Value1 1/2"-6UNC
AttributeN	Value28 mm	Value1-1/8"
